The Marlin 7 is your best friend on the trail and wherever else you roll thanks to its confidence-boosting trail geometry. It finds the perfect balance between price and performance with a RockShox suspension fork that makes quick work of rocks and bumps in your path, and loads of gears from the SRAM NX Eagle 12-speed drivetrain.
*Please note – spec applies to all sizes unless listed separately
- *Frame
-
Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: S , M , ML , L , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
- *Fork
-
Size: XS , S
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M , ML , L , XL , XXL
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
- Hub front
-
Formula DC-20 LW, alloy, 6-bolt, 100x5 mm
- Hub rear
-
Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm
- Skewer rear
-
- *Rim
-
Size: XS , S , M , ML , L , XL , XXL
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
- *Tyre
-
Size: XS , S
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.40''
Size: M , ML , L , XL , XXL
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40''
- Rim strip
-
- Shifter
-
- Rear derailleur
-
- *Crank
-
Size: XS , S , M
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length
Size: ML , L , XL , XXL
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length
- Bottom bracket
-
Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle
- Cassette
-
SRAM PG-1210 Eagle, 11-50, 12-speed
- Chain
-
- Pedal
-
- Saddle
-
- *Seatpost
-
Size: XS , S
TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm length
Size: M
TranzX JD-YSI34, 125 mm travel, internal routing, 31.6 mm, 405 mm length
Size: ML , L
TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm length
Size: XL , XXL
TranzX JD-YSI34, 170 mm travel, internal routing, 31.6 mm, 500 mm length
- *Handlebar
-
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
- Grips
-
- *Stem
-
Size: XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
- Head set
-
- Brake
-
Shimano MT200 hydraulic disc
- *Brake rotor
-
Size: XS , S , M , ML , L , XL , XXL
Shimano RT26, 6-bolt, 160 mm
Size: M , ML , L , XL , XXL
Shimano RT26, 6-bolt, 180 mm
- Brake Set
-
Shimano MT200 hydraulic disc
- Weight
- M - 14.15 kg / 31.2 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
