Trek Checkpoint SL 5 AXS Gen 3
Trek Checkpoint SL 5 AXS Gen 3
Trek Checkpoint SL 5 AXS Gen 3
Trek Checkpoint SL 5 AXS Gen 3
Trek Checkpoint SL 5 AXS Gen 3

Trek Checkpoint SL 5 AXS Gen 3

£2,900.00



SKU: 5321637

Product Details

The Checkpoint SL 5 AXS Gen 3 is an adventure-ready carbon gravel bike built to roll into the distant horizon. Its lightweight carbon frame is designed with comfort-focused geometry, room for beefy 50 mm tyres (as measured), and plenty of frame and fork mounts. Plus, IsoSpeed comfort technology helps soak up jarring road vibrations, so you can you float over chatter and potholes. It comes equipped with a wireless SRAM Apex XPLR AXS drivetrain to deliver plenty of gears for exploring the dusty road.



*Please note – spec applies to all sizes unless listed separately

Frame
500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle
Fork
Checkpoint full carbon, tapered carbon steerer, mudguard mounts, triple rack mounts, flat-mount disc, 12x100 mm chamfered thru axle

Weight
ML – 9.50 kg/20.95 lb (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

Battery
SRAM AXS battery pack (with charger)

Rear derailleur
SRAM Apex XPLR eTap AXS, 44T max cog
*Crank
Size: XS, S
SRAM Apex 1, 40T, DUB Wide, 165 mm length
Size: M
SRAM Apex 1, 40T, DUB Wide, 170 mm length
Size: ML, L
SRAM Apex 1, 40T, DUB Wide, 172.5 mm length
Size: XL
SRAM Apex 1, 40T, DUB Wide, 175 mm length
Bottom bracket
SRAM DUB Wide, T47 threaded, internal bearing
Cassette
SRAM XPLR PG-1231, 11-44, 12-speed
Chain
SRAM Apex, 12-speed
Max. chainring size
1x:44 2x: 46/30

Wheel front
Bontrager Paradigm SL, Tubeless Ready, 21 mm rim width, 100x12 mm thru axle
Hub front
Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Skewer front
Bontrager Switch chamfered thru axle
Hub rear
Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear
Bontrager Switch chamfered thru axle, removable lever
*Rim
Size: XS, S, M, ML, L, XL
Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve
Size: XS, S, M, ML, L, XL
Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager Girona RSL, Tubeless Ready, GR puncture protection, aramid bead, 220 tpi, 700x42 mm
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Max tyre size
50 mm without mudguards, 42 mm with mudguards (as measured, see manual for details)

*Saddle
Size: XS, S
Verse Short Comp, steel rails, 155 mm width
Size: M, ML, L, XL
Verse Short Comp, steel rails, 145 mm width
Seatpost
Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
*Handlebar
Size: XS
Bontrager Elite Gravel, alloy, 40 cm width
Size: S, M
Bontrager Elite Gravel, alloy, 42 cm width
Size: ML, L
Bontrager Elite Gravel, alloy, 44 cm width
Size: XL
Bontrager Elite Gravel, alloy, 46 cm width
Handlebar tape
Bontrager Supertack Perf tape
*Stem
Size: XS
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: S
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: M, ML
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: L
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: XL
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Brake rotor
SRAM Paceline, rounded, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 180 mm front and rear

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
