Product Details
MTB Frame details
- Headtube: ZS44/EC44 headset included
- Alloy seatpost collar included
- UDH hanger included
- Robert Axle Project Rear 148x12mm Boost thru axle included
- Seatpost: 31.6 mm (dropper post ready)
- Bottom bracket: 73mm BSA
- Brake standard: Direct-mount 160mm
- Fork travel: 100 – 120mm
- Available with carbon or suspension fork
- Wheel Size: 29″
- Tire size: up to 29×2.4”
- Max Chainring: up to 38t
- Frame weight 2.1 kg
- Butted tubes
- Grade 9 3Al-2.5V
- Lifetime Frame Warranty
Geometry, Weight & Specs
Build details:
Product Type | Component |
Bar Tape / Grips | BBB |
Frame | Gloria - Titanium FKTi |
Fork | ROCKSHOX FORK JUDY SILVER TK - CROWN 29" BOOST™ 15X110 ALUM STR |
Handle Bar | PRO Koryak E Performance 800 x 40 mm rise |
Saddle | Selle Itallia |
Stem | Zipp Service Course Stem |
Tyre | Schwalbe Racing Ralph Tubeless |
Wheel Pair | E 1900 wheelset, 30 mm rim ,29 inch |
Bottom Bracket | BB-RS501 bottom bracket cups, English thread cups |
Seat Post | Zipp Service Course 31.6 x 400mm |
Groupset | Deore M6100 12speed |
Cassette | Shimano CS-M6100 12-speed cassette 10 - 51T |
Chain | CNM7100126Q CN-M7100 SLX/105 HG+ chain with quick link, 12-speed, 126L |
Crank Set | FC-M6100 Crankset without ring, 12-speed, 52 mm chainline |
Head Set | Gloria ZS44/EC44 |
Head Set spacer | Headset Spacer Set / 1 1/8" / 2 x 10mm / Black |
Brakes | Shimano Deore M6100 | Hydraulic | Post mount |
Shifter | Shimano Deore M6100 | 1x | 12-speed |
Rear Mech | Shimano Deore M6100 | Long cage | 12-speed |
Seat Clamp | Gloria Forged Alloy Bolt Up 34.9 |
Rotors | Shimano RT66 | 180mm (front), 160mm (rear) | 6-bolt |
