Frame description
A lighter touring bike means you can take more with you, but low weight is no good without strength. That's why, for the CUBE Kathmandu Hybrid C:62, we used our tried-and-tested C:62 carbon to build a frame structure that combines the load-bearing capacity you need with the comfort and ride handling that you'd expect from CUBE. With a UDH derailleur hanger, Advanced Internal Cable Routing and Boost front and rear axles, it's both elegant and easy to live with. The rigid carbon fork is light and responsive, while the IC 3.0 rear carrier is adaptable and offers a sturdy platform for carrying whatever you need to take with you. Add the 400Wh battery, and it's the complete package for lightweight hybrid touring.
Frame descriptionWhen only the best will do, it's time to break out Shimano's XT components. Famed for their ease of use, precision and dependability, the wide-ranging 1x12 electronic gears and powerful hydraulic disc brakes are the obvious choice for the Kathmandu Hybrid C:62 SLT. Bosch's SX motor with 400Wh battery delivers up to 60Nm of pedal assistance with a significant weight saving. Combined with the lightweight C:62 carbon frame and fork plus carbon Newmen Phase 30 wheels, the result is a notably svelte grand tourer – and that means one that's easier and more fun to ride. It's just as practical as ever, though, with our super-sturdy IC 3.0 Integrated Carrier and a full complement of accessories. Across town or across continents, it's got your back.
SpecificationA lighter touring bike means you can take more with you, but low weight is no good without strength. That's why, for the CUBE Kathmandu Hybrid C:62, we used our tried-and-tested C:62 carbon to build a frame structure that combines the load-bearing capacity you need with the comfort and ride handling that you'd expect from CUBE. With a UDH derailleur hanger, Advanced Internal Cable Routing and Boost front and rear axles, it's both elegant and easy to live with. The rigid carbon fork is light and responsive, while the IC 3.0 rear carrier is adaptable and offers a sturdy platform for carrying whatever you need to take with you. Add the 400Wh battery, and it's the complete package for lightweight hybrid touring.
| FrameSpecification | C:62® Advanced Twin Mold, Efficient Comfort Geometry, Boost148, Fixed Integrated Battery, Flat Mount Disc, Integrated Carrier 3.0, Advanced Internal Cable Routing, UDH™ | Frame
|---|---|
| Fork | CUBE C:62® Technology, 1 1/2" - 1 1/2" Tapered, Internal Light Cable Option, 15x110mm | Fork
| Headset | ACROS AZF-1035, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) | Headset
| Stem | CUBE Performance Stem Pro, 31.8mm | Stem
| Handlebar | CUBE Comfort Trail Bar, 700mm | Handlebar
| Grips | ACID Travel Comfort | Grips
| Rear derailleur | Shimano XT Di2 RD-M8260-SGS, 12-Speed, Electronic Shifting System | Rear derailleur
| Shifters | Shimano XT Di2 SW-M8250-IR, Direct Attach | Shifters
| Brakes | Shimano XT BR-M8100, Hydr. Disc Brake (180/180) | Brakes
| Crankset | ACID MTB Hybrid Carbon, 38T | Crankset
| Crankset chainring sizes | 38T | Crankset chainring sizes
| Cassette | Shimano XT CS-M8100, 10-51T | Cassette
| Number of gears | 12 | Number of gears
| Chain | Shimano CN-M6100 | Chain
| Wheelset | Newmen Phase 30 light/base, 28/28 Spokes, 15x110mm / 12x148mm, Tubeless Ready | Wheelset
| Tires (Front & Rear) | Schwalbe G-ONE Overland, PerfL, 50-622 | Tires (Front & Rear)
| Pedals | ACID PP Trekking | Pedals
| Saddle | ACID Sequence 180 |
| Rear light | ACID Front Light PRO-E 200 X-Connect, 12V, DCACID Mudguard Rear Light PRO-E, 12V, DC |
| Kickstand | ACID Mudguard Rear Light PRO-E, 12V, DCACID FM Pure Kickstand |
| Mudguard | ACID FM Pure KickstandACID 60 Integrated Carrier 3.0 |
| Bell | ACID 60 Integrated Carrier 3.0Knog Oi |
| Carrier | Knog OiACID Integrated Carrier 3.0, CUBE Adapter Compatible |
| Engine | ACID Integrated Carrier 3.0, CUBE Adapter CompatibleBosch Drive Unit Performance SX max. 60Nm (BDU31) |
| Battery | Bosch Drive Unit Performance SX max. 60Nm (BDU31)Bosch CompactTube 400 |
| Charger | Bosch CompactTube 400Bosch 4A |
| Remote | Bosch 4ABosch LED Remote |
| Display | Bosch LED RemoteBosch Kiox 500 |
| Net weight (kg) | Bosch Kiox 50016.4 |
| Gross weight (kg) | 16.421.36 |
| Max. system weight (kg) | 21.36135 |
| Max. rider weight (kg) | 135110 |
| Body size | 1101.66m - 1.76m |
| Accessories | 1.66m - 1.76m93339,94799,93483,93354,93490,93592 |
