Fuel EX Aluminum Frameset offers near-limitless possibilities for your dream mountain bike build. Keep it classic with a 145/150mm setup and 29er wheels for ride-anything EX capability, go 150/160mm with MX wheels to get rowdy, or step up to a 160/170mm 29er LX build for more aggressive terrain. With its highly adjustable design, Fuel EX is ready to be built your way.

Technology

Adapt, rip, repeat - Only you can define your perfect trail bike – that's why Fuel is available in three adjustability-packed configurations. Get do-it-all capability with EX, go pop-happy with MX or charge through it all with LX.

Specification

Frame	Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm Alpha NEXT P
Frame Material	ALUMINIUM
Rim Size	29
Fork	RockShox
Fork	RockShox Lyrik Ultimate, DebonAir+ w/ ButterCups, Charger 3.1 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 150mm travel
Rearsuspension	RockShox
Suspension Rear	RockShox Deluxe Ultimate RC2T, 205 mm x 60 mm
Wheels	Bontrager Line Comp 30
Tires	Maxxis Minion DHF, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5" // Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5" // Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5"
Shifter	SRAM
Derailleur Rear	SRAM Eagle 90, T-Type
Crank	SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length // SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 165 mm length
Bottom Bracket	SRAM DUB MTB Wide, 73 m, BSA threaded
Cassette	SRAM Eagle XS-1275, T-Type, 10-52, 12-speed
Chain	SRAM GX Eagle, T-Type, 12-speed
Brake	SRAM
Brakeset	SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc SRAM Maven Bronze 4-piston hydraulic disc // SRAM Maven Bronze 4-piston hydraulic disc
Brake Rotor	SRAM HS2, 6-bolt, 180mm // SRAM HS2, 6-bolt, 200mm
Saddle	Verse Short Comp, steel rails, 145 mm width
Seatpost	Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar	Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width
Stem	Bontrager Elite, 35 mm, 0-degree, 45 mm length
Grips	Trek Line Elite, lock-on
Size Chart Rider Height	Rider Height - 177.0 - 188.0
Size Chart Rider Inseam	Inseam - 84.0 - 89.0
