Kona Splice Hybrid Bike

Kona Splice Hybrid Bike

Size
Quantity
Looking to purchase with a cycle to work scheme?

Click here to get in touch and get the ball rolling!

The Splice strikes that coveted balance of bike path-cruiser and hybrid comfort. It’s the perfect complement to a camping trip, the perfect steed for rides through the local park, and it’s also a great commuter. It’s got modern geometry that provides an excellent fit with a shorter reach and the ability to run a dropper post. The Splice has just enough suspension up front that you can lock out for efficient pedaling, hydraulic disc brakes for powerful stopping, and sturdy wheels and tires. It may just tempt you to explore further than ever before.


SPECIFICATIONS

FRAME MATERIAL Kona 6061 Aluminum Butted
SIZES S, M, L, XL
REAR SHOCK n/a
FORK Suntour NEX Coil Spring 80mm
CRANKARMS Shimano
CHAINRINGS 22/32/42t
B/B FSA 68mm
PEDALS Kona JS2
CHAIN KMC Z8.3
CASSETTE Shimano Altus 11-34t 8spd
CHAINGUIDE n/a
F/D Shimano Tourney
R/D Shimano Tourney
SHIFTERS Shimano Altus
BRAKE CALIPERS Clarks M2 Hydraulic
FRONT BRAKE ROTOR Clarks M2 160mm
REAR BRAKE ROTOR Clarks M2 160mm
BRAKE LEVERS Clarks M2 Hydraulic
HEADSET Feimin FP-H863
HANDLEBAR Kona Aluminum Riser
STEM Kona Control
SEATPOST Kona Thumb w/Offset 31.6mm
SEAT CLAMP Kona Clamp
GRIPS Kona Key Grip Slip on
SADDLE Kona Crosstrail
FRONT HUB Formula 100x9mm
REAR HUB Formula 135x10mm
SPOKES Stainless Black 14g
RIMS Double Wall alloy
FRONT TIRE WTB Riddler 700x45c
REAR TIRE WTB Riddler 700x45c
PAINT COLOR Satin Black w/ Metallic Mint & Metallic Silver Decals
EXTRAS n/a

All specifications are subject to change without notice

GEOMETRYmminches

  SIZE S M L XL
1 ST LENGTH 381 432 483 533
2 TT LENGTH 572 597 623 647
3 REACH 398 419 439 458
4 STACK 590 603 622 641
5 STANDOVER 691 734 773 812
6 HT ANGLE 70.0 70.0 70.0 70.0
7 HT LENGTH 110 130 150 170
8 ST ANGLE 73.5 73.5 73.5 73.5
9 CS LENGTH 440 440 440 440
10 BB DROP 58 53 53 53
11 BB HEIGHT 297 302 302 302
12 WHEELBASE 1072 1100 1127 1153
13 FRONT CENTER 638 666 692 718
14 FORK LENGTH 467 467 467 467
15 FORK OFFSET 42 42 42 42
KONA Geometry

SIZING + FIT

GRAVEL / DROP BAR / URBAN

HEIGHT/INCHES HEIGHT/METRIC INSEAM/INCHES INSEAM/METRIC ROVE LIBRE SUTRA DEWS COCO
4'10"-5'1" 147-155cm 24”-27” 61-69cm 48cm 50cm 48cm N/A XS
5'0"-5'3" 152-160cm 26"-29" 66-74cm 48-50cm 50cm 48-50cm Small Small
5'2"-5'7" 157-170cm 27"-30" 69-76cm 48-52cm 50-52cm 48-52cm Small, Medium Small, Medium
5'6"-5'10" 168-178cm 29"-31" 74-79cm 52-54cm 52-54cm 52-54cm Medium Medium
5'9"-6'0" 175-183cm 30"-33" 76-84cm 52-56cm 54-56cm 54-56cm Medium, Large Medium, Large
5'11"-6'2" 180-188cm 32"-35" 81-89cm 54-58cm 54-58cm 54-58cm Large, XL Large
6'1"-6'5" 185-196cm 33"-36" 84-91cm 56-58cm 58cm 56-58cm XL N/A

MTB / ALL MOUNTAIN / SPLICE

HEIGHT/INCHES HEIGHT/METRIC INSEAM/INCHES INSEAM/METRIC MTB/XC TRAIL/FAT ALL MOUNTAIN/ENDURO SPLICE
4'10"-5'1" 147-155cm 24”-27” 61-69cm XS XS Small
5'0"-5'3" 152-160cm 26"-29" 66-74cm Small Small Small
5'2"-5'7" 157-170cm 27"-30" 69-76cm Small, Medium Small, Medium Small, Medium
5'6"-5'10" 168-178cm 29"-31" 74-79cm Medium Medium Medium
5'9"-6'0" 175-183cm 30"-33" 76-84cm Medium, Large Medium, Large Medium, Large
5'11"-6'2" 180-188cm 32"-35" 81-89cm Large, XL Large, XL Large, XL
6'1"-6'5" 185-196cm 33"-36" 84-91cm Large, XL Large, XL Large, XL

Thanks for considering ProjektRide for your next purchase. All bikes are fully assembled and test rode before leaving our bike shop in Edinburgh.  Please allow 5-7 days for bicycle delivery although we aim to post bikes out the same day.

If any purchases are to be made using any cycle to work schemes, please either pop into the shop or get in touch via email/phone to get the ball rolling. If you are not 100% sure with bike sizing, please feel free to contact us to double check.

All bike sales include a free running in service after 6-10 weeks.
