Checkpoint SL 6 AXS Pro Gen 3 is a carbon gravel bike ready for far-out adventures. Its lightweight 500 Series OCLV Carbon frame is built with comfort-focused Gravel Endurance geometry, clearance for beefy 50mm tires (as measured), and mounts for racks, fenders, and bags. IsoSpeed frame technology smooths out rough roads and potholes so you can ride stronger longer, while wireless SRAM Rival AXS E1 13-speed shifting, Aeolus Elite 35V carbon wheels, and a carbon handlebar keep the ride light, capable, and ready to cut loose whenever you are.

Technology

IsoSpeed comfort tech - IsoSpeed comfort tech smooths pot holes and fatiguing bumps in the road so you can ride stronger for longer.

Specification

Frame	500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden mudguard mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12 mm chamfered thru axle
Frame Material	CARBON
Rim Size	28
Fork	Trek
Wheels	Bontrager Aeolus Elite 35V
Tires	Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm
Derailleur Rear	SRAM Rival XPLR AXS, 46T max cog
Cassette	SRAM Rival XPLR XG-1351, 10-46, 13-speed
Chain	Sram Rival E1 12/13-Speed
Saddle	Verse Short Comp, steel rails, 145 mm width
Seatpost	Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
Handlebar	Bontrager Pro Gravel, 44 cm width
Stem	Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length
Battery	SRAM AXS battery pack (with charger) SRAM AXS battery pack (with charger)
Size Chart Rider Height	Rider Height - 188.0 - 194.0
Size Chart Rider Inseam	Inseam - 88.0 - 91.0
